| Camera |
| Image Sensor |
Channel 1 (PT Lens): 1/2.9″ CMOS Channel 2 (Fixed Lens): 1/2.9″ CMOS |
| Max. Resolution |
Channel 1 (PT Lens): 1920 (H) × 1080 (V) Channel 2 (Fixed Lens): 1920 (H) × 1080 (V) |
| ROM |
128 MB |
| RAM |
256 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.0006 lux@F1.0 |
| S/N Ratio |
>56 dB |
| Illumination Distance |
Up to 30 m (98.43 ft) (Warm light) |
| Illuminator On/Off Control |
Auto; Manual |
| Illuminator Number |
4 (Warm light) |
| Lens |
| Lens Type |
Channel 1 (PT Lens): Fixed-focal Channel 2 (Fixed Lens): Fixed-focal |
| Lens Mount |
M12 |
| Focal Length |
Channel 1 (PT Lens): 3.6 mm Channel 2 (Fixed Lens): 3.6 mm |
| Max. Aperture |
Channel 1 (PT Lens): F1.0 Channel 2 (Fixed Lens): F1.0 |
| Field of View |
Channel 1 (PT Lens): H: 81°; V: 44°; D: 95° Channel 2 (Fixed Lens): H: 81°; V: 44°; D: 95° |
| Iris Control |
Fixed |
| Close Focus Distance |
Channel 1 (PT Lens): 1.7 m (5.58 ft) Channel 2 (Fixed Lens): 1.7 m (5.58 ft) |
| DORI Distance |
| Lens |
Channel 1 (PT Lens) |
| Detect |
55.7 m (182.74 ft) |
| Observe |
22.3 m (73.16 ft) |
| Recognize |
11.1 m (36.42 ft) |
| Identify |
5.6 m (18.37 ft) |
| Lens |
Channel 2 (Fixed Lens) |
| Detect |
55.7 m (182.74 ft) |
| Observe |
22.3 m (73.16 ft) |
| Recognize |
11.1 m (36.42 ft) |
| Identify |
5.6 m (18.37 ft) |
| Note |
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
| Intelligence |
| IVS (Perimeter Protection) |
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
| SMD |
SMD Plus |
| Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| Video Frame Rate |
Channel 1 (PT Lens): Main stream: 1920 × 1080@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) Channel 2 (Fixed Lens): Main stream: 1920 × 1080@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Streaming Capability |
2 streams |
| Resolution |
Channel 1 (PT Lens): 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) Channel 2 (Fixed Lens): 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
VBR; CBR |
| Video Bit Rate |
H.264: 32 kbps–4096 kbps; H.265: 12 kbps–4096 kbps |
| Day/Night |
Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| LDC |
Yes |
| Audio |
| Built-in MIC |
Yes, built-in Mic |
| Built-in Speaker |
Yes, built-in speaker |
| Audio Compression |
G.711a; G.711Mu; PCM; G.726 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception |
| Network |
| Network Port |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration |
| Security |
Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade; Session security; Security warning |
| Interoperability |
ONVIF (Profile S & Profile G & Profile T); CGI |
| User/Host |
20 (Total bandwidth: 48 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 GB); NAS |
| Browser |
IE; Chrome; Firefox |
| Management Software |
Smart PSS Lite; DSS; DMSS |
| Mobile Client |
Android;iOS |
| Function |
| Light Warning |
Warm light warning Flash/Solid on duration: 5 s–30 s Flash frequency: high, medium, low |
| Sound Warning |
Offers 3 sound alarms and supports importing custom sound alarms. Sound: 0–100. Play times can be set from 1 to 10. |
| PTZ |
| Pan/Tilt Range |
Channel 1 (PT Lens): Pan: 0° to 350°; Tilt: 0° to 90°; Channel 2 (Fixed Lens): Pan: 0° to 326°; Tilt: –10° to 15° |
| Manual Control Speed |
Pan: 0.1°/s–55.4°/s; Tilt: 0.1°/s–29.3°/s |
| Preset |
300 |
| Preset Speed |
Pan: 55.4°/s; Tilt: 29.3°/s |
| Tour |
8 (up to 32 presets per tour) |
| Power-off Memory |
Yes |
| Idle Motion |
Tour;Preset |
| Certification |
| Certifications |
CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
| Power |
| Power Supply |
12 VDC (±30%); PoE (802.3af) |
| Power Consumption |
Basic: 2.3 W (12 VDC); 3.1 W (PoE); Max.: 9.2 W (12 VDC); 10.5 W (PoE) (intelligence on + WDR + illuminator on + PT rotation + speaker on) |
| Environment |
| Operating Temperature |
–40 °C to +50 °C (–40 °F to +122 °F) |
| Operating Humidity |
≤95% (RH), non-condensing |
| Storage Temperature |
–40 °C to +50 °C (–40 °F to +122 °F) |
| Storage Humidity |
≤95% (RH), non-condensing |
| Protection |
IP66 |
| Structure |
| Casing Material |
Plastic |
| Product Dimensions |
159.4 mm × 110.1 mm × 210 mm (6.28″ × 4.33″ × 8.27″) (L × W × H) |
| Net Weight |
0.62 kg (1.37 lb) |
| Gross Weight |
0.87 kg (1.92 lb) |
