| System |
| Main Processor <!–{v.name}–> | Industrial-grade processor |
| Operating System <!–{v.name}–> | Embedded Linux |
| Operating Interface <!–{v.name}–> | Web, Local GUI |
| AI |
| AI by Recorder <!–{v.name}–> | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus |
| AI by Camera <!–{v.name}–> | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD; stereo analysis, crowd distribution; people counting; ANPR; heat map; PPE detection |
| AcuPick AI by Camera + Recorder <!–{v.name}–> | Max. 64-channel, 1 combined event per channel |
| Perimeter Protection |
| Perimeter Performance AI by Recorder (Number of Channels) <!–{v.name}–> | Simultaneous mode: 32 channels, 10 IVS rules for each channel Heterogeneous mode: 24 channels, 10 IVS rules for each channel Refer to the information on video output for details on the mode |
| Perimeter Performance of AI by Camera (Number of Channels) <!–{v.name}–> | All channels (64 targets/s) |
| Face Detection |
| Face Attributes <!–{v.name}–> | 6 attributes |
| Face Detection Performance of AI by Recorder (Number of Channels) <!–{v.name}–> | Simultaneous mode: 8 channels (up to 12 face images/s each channel) Heterogeneous mode: 5 channels (up to 12 face images/s each channel) Refer to the information on video output for details on the mode |
| Face Detection Performance of AI by Camera (Number of Channels) <!–{v.name}–> | 64 channels |
| Face Recognition |
| Face Database Capacity <!–{v.name}–> | Up to 40 face databases with 300,000 images, with a total capacity of 48 G. |
| Face Recognition Performance of AI by Recorder (Number of Channels) <!–{v.name}–> | Simultaneous mode: 32-channel FD (by camera) + FR (by recorder),image stream: 32 face images/s; 8-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s Heterogeneous mode: 16-channel FD (by camera) + FR (by recorder),image stream: 16 face images/s; 5-channel FD (by recorder) + FR (by recorder), video stream: 10 face images/s Refer to the information on video output for details on the mode |
| Face Recognition Performance of AI by Camera (Number of Channels) <!–{v.name}–> | 64 channels |
| SMD Plus |
| SMD Plus by Recorder <!–{v.name}–> | 32 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera <!–{v.name}–> | All channels (128 targets/s) |
| Video Metadata |
| Metadata Performance of AI by Recorder (Number of Channels) <!–{v.name}–> | 8 channels, 23 attributes extraction. |
| Metadata Performance of AI by Camera (Number of Channels) <!–{v.name}–> | 64 channels |
| People Attributes <!–{v.name}–> | 9 human body attributes |
| Motor Vehicle Attributes <!–{v.name}–> | 9 attributes |
| Non-motor Vehicle Attributes <!–{v.name}–> | 4 attributes |
| Vehicle License Plate Comparison |
| ANPR by Camera (Number of Channels) <!–{v.name}–> | All channels (64 targets/s) |
| License Plate Database Capacity <!–{v.name}–> | 1. Up to 20,000 plate numbers. 2. Blocklist and allowlist |
| Audio and Video |
| Access Channel <!–{v.name}–> | 128 channels |
| Network Bandwidth <!–{v.name}–> | AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing |
| Resolution <!–{v.name}–> | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF |
| Decoding Capability <!–{v.name}–> | AI disabled: 2-channel 32 MP@30 fps; 2-channel 24 MP@30 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 11-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps；128-channel D1@30 fps AI enabled: 1-channel 32 MP@30 fps; 1-channel 24 MP@30 fps; 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 5-channel 6 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps； 80-channel D1@30 fps |
| Video Output <!–{v.name}–> | 2 VGA, 4 HDMI; VGA: 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720 Simultaneous mode (simultaneously outputs video sources for all the HDMI1-4 and VGA1-2 ports) Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1 and HDMI2 is 4K; max. resolution of HDMI3 is 8K; max. resolution of HDMI4 is 1080p Heterogeneous mode (simultaneously outputs video sources for the VGA1 and HDMI1, or VGA2 and HDMI2. It also outputs heterogeneous video sources for HDMI1–4) Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1, HDMI2 and HDMI3 is 4K; max. resolution of HDMI4 is 1080p |
| Multi-screen Display <!–{v.name}–> | Main Screen: 1/4/8/9/16/25/36/64 Sub Screen: 1/4/8/9/16/25/36 |
| Third-party Camera Access <!–{v.name}–> | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha |
| Compression Standard |
| Video Compression <!–{v.name}–> | Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio Compression <!–{v.name}–> | G.711a; G.711u; PCM; G726 |
| Network |
| Network Protocol <!–{v.name}–> | HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI |
| Mobile Phone Access <!–{v.name}–> | iOS; Android |
| Interoperability <!–{v.name}–> | ONVIF 22.06(Profile T; Profile S; Profile G); CGI; SDK |
| Browser <!–{v.name}–> | Chrome; IE; Safari; Edge; Firefox |
| Network Mode <!–{v.name}–> | Multi-address; load balance; fault tolerance |
| Recording Playback |
| Multi-channel Playback <!–{v.name}–> | Up to 16 channels |
| Record Mode <!–{v.name}–> | General, motion detection; intelligent; alarm; POS |
| Backup Method <!–{v.name}–> | USB device and network |
| Playback Mode <!–{v.name}–> | Instant playback; general playback; event playback; tag playback; smart playback |
| Storage |
| Disk Group <!–{v.name}–> | Yes |
| RAID <!–{v.name}–> | RAID 0/1/5/6/10 |
| Hot Swapping <!–{v.name}–> | Yes |
| Alarm |
| General Alarm <!–{v.name}–> | Motion detection; local alarm; alarm box; camera external alarm; network alarm; scene changing; PIR alarm; thermal alarm |
| Anomaly Alarm <!–{v.name}–> | Error (no disk, disk error, low space, RAID exception, low quota space; abnormal disk health; network disconnection; IP conflict; MAC conflict; abnormal fan speed); video loss; video tampering; camera offline; audio detection |
| Intelligent Alarm <!–{v.name}–> | Face detection; face and body detection; face recognition; perimeter protection; SMD; video metadata; stereo analysis, crowd distribution; ; ANPR; heat map |
| Alarm Linkage <!–{v.name}–> | Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; email |
| Port |
| Audio Input <!–{v.name}–> | 1-channel RCA |
| Audio Output <!–{v.name}–> | 2-channel RCA |
| Alarm Input <!–{v.name}–> | 32 channels |
| Alarm Output <!–{v.name}–> | 16 channels |
| Disk Interface <!–{v.name}–> | 16 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature. |
| eSATA <!–{v.name}–> | 1 |
| RS-232 <!–{v.name}–> | 1 |
| RS-485 <!–{v.name}–> | 2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication) |
| USB <!–{v.name}–> | 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports) |
