| Camera |
| Camera Case Type |
Bullet;Dome |
| Image Sensor |
1/3″ Progressive Scan CMOS |
| Min. Illumination |
Bullet:Color: 0.01 Lux @ (F2.0, AGC ON),B/W: 0 Lux with IR Dome:Color: 0.04 Lux @ (F2.0, AGC ON),B/W: 0.01 Lux @ (F2.0, AGC ON),0 Lux with IR |
| Day & Night |
IR cut filter |
| WDR |
DWDR |
| Angle Adjustment |
Bullet: Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° Dome: Pan: 0° to 345°,tilt: 0° to 80° |
| Protection Level |
IP66 |
| Wi-Fi Support |
Yes |
| Camera/Lens |
| Focal Length |
2.8 mm |
| Aperture |
F2.0 |
| Focus |
Fixed |
| FOV |
Horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118° |
| Camera/IR |
| IR Range |
Bullet:Up to 30 m Dome:White light distance: up to 25 m,IR distance: up to 25 m |
| Camera/Compression Standard |
| Video Compression |
H.265;H.264;MJPEG |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Audio Compression |
G.711/AAC-LC |
| Audio Bit Rate |
64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate |
8 kHz/16 kHz |
| Environment Noise Filtering |
Yes |
| Camera/Image |
| Max. Resolution |
2MP |
| Main Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 768 x 432) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 768 x 432) |
| Sub-stream |
50 Hz: 25 fps (768 × 432) 60 Hz: 30 fps (768 × 432) |
| Image Setting |
Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
| Day/Night Switch |
Auto/Scheduled/Day/Night |
| Camera/Network |
| Alarm Trigger |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv6, UDP, QoS, UPnP |
| General Function |
One-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Camera/Interface |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Reset Button |
Yes |
| Camera/General |
| Power Supply |
Bullet: 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection,A switching adapter is included in the package. Dome: 12 VDC ± 25%, reverse polarity protection, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug |
| Consumption |
Bullet: ≤ 6 W Dome: ≤ 9 W |
| Working Temperature |
Bullet: -30 °C to 60 °C (-22 °F to 140 °F) Dome: -10 °C to 40 °C (-14 °F to 104 °F) |
| Working Humidity |
95% or less (non-condensing) |
| Dimension (W × D × H) |
Bullet: 260.9 mm × 113.9 mm × 67.4 mm (10.3″ × 4.5″ × 2.7″) Dome: Ø124 mm × 119 mm (Ø4.89 × 4.68″) |
| Weight |
Bullet: 305 g (0.67 lb.) Dome: 600 g (1.32 lb.) |
| NVR/Video and Audio |
| IP Video Input |
4-ch |
| Incoming/Outgoing Bandwidth |
20 Mbps/20 Mbps |
| NVR/Decoding |
| Video Resolution |
6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
| Synchronous Playback |
1-ch |
| NVR/Network |
| Network Interface |
1, RJ45 10/100M Ethernet interface |
| NVR/Wi-Fi |
| Frequency Band |
2.4 GHz |
| Antenna Structure |
High gain antenna |
| Transmission Speed |
150 Mbps |
| Transmission Standard |
IEEE 802.11b/g/n/ax |
| NVR/Auxiliary Interface |
| SD Card |
32G/64G/128G/256G/512G |
| NVR/General |
| Power Supply |
12 VDC |
| Consumption (without HDD and PoE off) |
≤ 6 W |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Dimension (W × D × H) |
163 x 125 x 26 mm (6.4″ × 4.9″ × 1.0″) |
| Weight (without hard disk) |
≤ 500g |
| Kit |
| Accessories |
Power adaptor: 2 × IPC power adaptor, 1 × NVS power adaptor Ethernet cable: RJ45, Cat5e UTP, 1 m |
| Certification |
CB, CE |
| Weight (with package) |
≤ 2.5 kg (5.5 lb) |
