| Camera |
| Image Sensor |
1/2.7″ CMOS |
| Max. Resolution |
2960 (H) × 1668 (V) |
| ROM |
4 GB |
| RAM |
1 GB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.0009 lux@F1.5(Color, 30 IRE)
0.0005 lux@F1.5(B/W, 30 IRE)
0 lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
Up to 60 m (196.85 ft) (IR) |
| Illuminator On/Off Control |
Auto; Zoom-prio; Manual |
| Illuminator Number |
4 (IR LED) |
| Angle Adjustment |
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens |
| Lens Type |
Motorized vari-focal |
| Lens Mount |
φ14 |
| Focal Length |
2.7 mm–13.5 mm |
| Max. Aperture |
F1.5 |
| Field of View |
H: 114°–32°, V: 58°–17°, D: 138°–36° |
| Iris Control |
Auto |
| Close Focus Distance |
0.8 m (2.62 ft) |
| DORI Distance |
| Lens |
Wide |
| Detect |
64.0 m (209.97 ft) |
| Observe |
25.6 m (83.99 ft) |
| Recognize |
12.8 m (41.99 ft) |
| Identify |
6.4 m (20.99 ft) |
| Lens |
Tele |
| Detect |
210.0 m (688.98 ft) |
| Observe |
84.0 m (275.89 ft) |
| Recognize |
42.0 m (137.80 ft) |
| Identify |
21.0 m (68.90 ft) |
| Intelligence |
| IVS (Perimeter Protection) |
Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle, animal and human); loitering detection, people gathering, parking detection. Supports long-distance mode. Supports self-learning. It filters out false alarms. |
| Smart Object Detection |
Smart abandoned object; smart missing object |
| SMD |
SMD 3.0 |
| AcuPick |
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people, animal and motor vehicles, and search through live and recorded videos to quickly locate targets. |
| AI SSA |
Yes |
| Face Detection |
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes and 8 expressions; face snapshot set as face, one-inch photo or custom; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting. |
| People Counting |
Tripwire people counting, generating and exporting report (day/week/month/year); people counting in area and queue management; generating and exporting report (day/week/month); 4 rules can be set for tripwire, people counting in area and queue management. |
| Heat Map |
Yes |
| Video Metadata |
Motor vehicle, non-motor vehicle, face, human body detection; track; snapshot; snapshot optimization; optimal face snapshot upload. |
| Video Metadata Attributes |
Motor vehicle attributes: vehicle type, vehicle color, vehicle logo and other attributes : seatbelt, smoking, calling.
Non-motor vehicle attributes: type, color, number of people, top type and color, hat.
Human body attributes: gender, top/bottom type and color, bag, hat and umbrella.
Face attributes: gender, age, expressions, glasses, face mask and beard. |
| Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Smart Sound Detection |
Yes |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265; AI H.264 |
| Video Frame Rate |
Main stream: 2960 × 1668@(1–25/30 fps)
Sub stream: D1@(1–25/30 fps)
Third stream: 1080p@(1–25/30 fps)
Fourth stream: 720p@(1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability |
4 streams |
| Resolution |
5M (2960 × 1668); 5M (2880 × 1620); 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps–16384 kbps; H.265: 12 kbps–11776 kbps |
| Day/Night |
Auto(ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation (SSA) |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Image Stabilization |
Electronic Image Stabilization (EIS) |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 4M (2688 × 1520) resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
8 areas |
| LDC |
Yes |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; PCM; G.726; G.723 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; external alarm; face detection; video metadata; SMD; people counting in area; stay detection; people counting; people number error detection; queue people number alarm; queue time alarm; security exception; defocus detection |
| Network |
| Network Port |
RJ-45 (10/100 Enhancement Base-T) |
| SDK and API |
Yes |
| Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Register |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T/Profile M); CGI |
| User/Host |
20 (Total bandwidth: 80 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 1 TB); NAS |
| Browser |
IE: IE 9 and later
Chrome: Chrome 102 and later
Firefox: Firefox 88 and later |
| Mobile Client |
iOS; Android |
| Security |
Trusted execution; Digest; Security logs; WSSE; Account lockout; Syslog; 802.1x; IP/MAC filtering; HTTPS; Trusted upgrade; Trusted boot; Generation and importing of X.509 certification |
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
2 channels in: wet contact, 5 mA 3V-5V DC |
| Alarm Output |
1 channel out: wet contact, 300mA 12V DC |
| Power |
| Power Supply |
12 VDC/PoE (802.3af)/ePoE |
| Dual Power Backup |
When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart. |
| Power Consumption |
Basic: 3.6 W (12 VDC); 4.7 W (PoE)
Max. (H.265+ WDR+ Intelligence on+IR on): 10.4 W (12 VDC); 13.0 W (PoE) |
| Environment |
| Operating Temperature |
-30 °C to +60 °C (-22 °F to +140 °F) |
| Operating Humidity |
≤95% |
| Storage Temperature |
-40 °C to +60 °C (-40 °F to +140 °F) |
| Storage Humidity |
10%-95% (RH), non-condensing |
| Protection |
IP67; IK10 |
| Structure |
| Casing Material |
Metal |
| Product Dimensions |
273.2 mm × 95.0 mm × 95.0 mm (10.76″ × 3.74″ × 3.74″) (L × W × H) |
| Net Weight |
1.12 kg (2.47 lb) |
| Gross Weight |
1.66 kg (3.66 lb) |
