| Camera |
| Image Sensor |
1/1.8″ CMOS |
| Max. Resolution |
3840 (H) × 2160 (V) |
| ROM |
256 MB |
| RAM |
2 GB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.0008 Lux@F1.0 (Color, 30IRE)
0.0004 Lux@F1.0 (B/W, 30IRE)
0 Lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
Up to 50 m (164.04 ft) (IR)
Up to 50 m (164.04 ft) (Warm light) |
| Illuminator On/Off Control |
Auto/Manual |
| Illuminator Number |
4 (Multi-core (IR + warm) light) |
| Angle Adjustment |
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed-focal |
| Lens Mount |
M16 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F1.0 |
| Field of View |
2.8 mm: H: 109°; V: 59°; D: 131°
3.6 mm: H: 93°; V: 50°; D: 111° |
| Iris Control |
Fixed |
| Close Focus Distance |
2.8 mm: 3.2 m (10.50 ft)
3.6 mm: 4.4 m (14.44 ft) |
| Lens DORI Distance |
2.8 mm: Detect: 82.0 m (269.03 ft); Observe: 32.8 m (107.64 ft); Recognize: 16.4 m (53.81 ft); Identify: 8.2 m (26.90 ft)
3.6 mm: Detect: 100.0 m (328.08 ft); Observe: 40.2 m (131.23 ft); Recognize: 20.0 m (65.62 ft); Identify: 10.0 m (32.81 ft) |
| Intelligence |
| NS (Perimeter Protection) |
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
| SMD |
SMD 4.0 |
| Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| AcuPick |
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets. |
| ALSSA |
Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions. |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265 (Compression rate ≥25%)
AI H.264 (Compression rate ≥25%) |
| Video Frame Rate |
Main stream: 3840 × 2160@(1 fps-25/30 fps)
Sub stream: 1920 × 1080@(1 fps-25/30 fps)
Third stream: 1920 × 1080@(1 fps-25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability |
3 streams |
| Resolution |
8M (3840 × 2160); 6M (3200 × 1800); 5M (3072 × 1728); 4M (2688 × 1520/2560 × 1440); 3M (3204 × 1296); 10600 (1920 × 1008); 720p (1280 × 720); UL [701 × 576/704 × 480]; VGA (640 × 480); CF (352 × 288/352 × 240) |
| Bit Rate Control |
VBR; GBR; ABR |
| Video Bit Rate |
H.264: 3 kbps–16384 kbps
H.265: 3 kbps–16384 kbps |
| Day/Night |
Auto(ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation (SSA) |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Smart Dual Light |
Yes |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
8 areas |
| LDC |
Yes |
| Audio |
| Built-in MIC |
Yes, built-in dual Mic |
| Built-in Speaker |
Yes, built-in speaker |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception |
| Network |
| Network Port |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; ODS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SIMAP; P2P |
| Interoperability |
ONVIF (Profile S; Profile G; Profile T); CGI |
| User/Host |
20 (Total bandwidth: 64 M) |
| Storage |
FTP/SFTP; Micro SD card (support max. 512 GB); NAS |
| Browser |
IE: IE11 Chrome Firefox |
| Mobile Client |
iOS; Android |
| Cyber Security |
| Cyber Security |
Video encryption; Firmware encryption; Configuration encryption; Digest; WSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS 802.1x; Trusted boot; Trusted execution; Trusted upgrade |
| Port |
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
1 channel in: wet contact, 5 mA 3–5 VDC |
| Alarm Output |
1 channel out: wet contact, 300 mA 12 VDC |
| Power |
| Power Supply |
12 VDC/PoE+ (802.3at) |
| Dual Power Backup |
When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart. |
| Power Consumption |
Basic: 4.3 W (12 VDC); 6.2 W (PoE)
Max. (H.265+WDR+ warm light+siren and light active deterrence + intelligence on): 11.8 W (12 VDC); 15.1 W (PoE) |
| Environment |
| Operating Temperature |
-40 °C to +60 °C (-40 °F to +140 °F) |
| Operating Humidity |
≤95% (RH), non-condensing |
| Protection |
IP67 |
| Storage Temperature |
-40 °C to +60 °C (-40 °F to +140 °F) |
| Storage Humidity |
≤95% (RH), non-condensing |
| Structure |
| Casing Material |
Metal + plastic |
| Product Dimensions |
288.4 mm × 94.4 mm × 84.7 mm (11.35″ × 3.72″× 3.33″) (L × W × H) |
| Net Weight |
1.0 kg (2.20 lb) |
| Gross Weight |
1.3 kg (2.87 lb) |
