| System |
| Main Processor
<!–{v.name}–> |
Industrial-grade processor |
| Operating System
<!–{v.name}–> |
Embedded Linux |
| Operating Interface
<!–{v.name}–> |
Web, Local GUI |
| AI |
| AI by Recorder
<!–{v.name}–> |
Face detection; face recognition; perimeter protection; SMD Plus |
| AI by Camera
<!–{v.name}–> |
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map |
| AcuPick AI by Camera + Recorder
<!–{v.name}–> |
Max. 32-channel, 1 combined event per channel/s |
| Perimeter Protection |
| Perimeter Performance AI by Recorder (Number of Channels)
<!–{v.name}–> |
4 channels, 10 IVS rules for each channel |
| Perimeter Performance of AI by Camera (Number of Channels)
<!–{v.name}–> |
All channels (16 targets/s) |
| Face Detection |
| Face Attributes
<!–{v.name}–> |
Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Recorder (Number of Channels)
<!–{v.name}–> |
2 channels (up to 12 face images/s each channel) |
| Face Detection Performance of AI by Camera (Number of Channels)
<!–{v.name}–> |
16 channels |
| Face Recognition |
| Face Database Capacity
<!–{v.name}–> |
Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. |
| Face Recognition Performance of AI by Recorder (Number of Channels)
<!–{v.name}–> |
1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s
2. 2-channe FD (by recorder) + FR (by recorder), video stream: 12 face images/s |
| Face Recognition Performance of AI by Camera (Number of Channels)
<!–{v.name}–> |
16 channels |
| SMD Plus |
| SMD Plus by Recorder
<!–{v.name}–> |
8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera
<!–{v.name}–> |
All channels (32 targets/s) |
| Video Metadata |
| Metadata Performance of AI by Camera (Number of Channels)
<!–{v.name}–> |
8 channels |
| Human Attributes
<!–{v.name}–> |
Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella |
| Motor Vehicle Attributes
<!–{v.name}–> |
License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location. |
| Non-motor Vehicle Attributes
<!–{v.name}–> |
Vehicle model, vehicle color, number of persons, helmet. |
| Vehicle License Plate Comparison |
| ANPR by Camera (Number of Channels)
<!–{v.name}–> |
All channels (8 targets/s) |
| License Plate Database Capacity
<!–{v.name}–> |
1. Create up to 20,000 plate numbers.
2. Blocklist and allowlist |
| Audio and Video |
| Access Channel
<!–{v.name}–> |
32 channels |
| Network Bandwidth
<!–{v.name}–> |
AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing
AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing |
| Resolution
<!–{v.name}–> |
32 MP;24 MP;16 MP;12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF;QCIF |
| Decoding Capability
<!–{v.name}–> |
AI disabled: 2-channel 32 MP@25 fps; 2-channel 24 MP@25 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 10-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps
AI enabled: 1-channel 32 MP@25 fps; 1-channel 24 MP@25 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 6-channel 8 MP@30 fps; 8-channel 6 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps; 24-channel 1080p@30 fps |
| Video Output
<!–{v.name}–> |
1 VGA, 1 HDMI
VGA:1920 × 1080, 1280 × 1024, 1280 × 720
HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
Heterogeneous video source output for HDMI and VGA |
| Multi-screen Display
<!–{v.name}–> |
Main screen: 1/4/8/9/16/25/36
Sub screen: 1/4/8/9/16 |
| Third-party Camera Access
<!–{v.name}–> |
ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha |
| Compression Standard |
| Video Compression
<!–{v.name}–> |
Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Audio Compression
<!–{v.name}–> |
G.711a; G.711u; PCM; G726 |
| Network |
| Network Protocol
<!–{v.name}–> |
HTTP; HTTPS; TCP/IP; IPv4; UDP; NTP; DHCP; DNS; SMTP; UPnP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI |
| Mobile Phone Access
<!–{v.name}–> |
iOS; Android |
| Interoperability
<!–{v.name}–> |
ONVIF 23.12(Profile T; Profile S; Profile G); CGI; SDK |
| Browser
<!–{v.name}–> |
Chrome; IE; Safari; Edge; Firefox |
| Recording Playback |
| Multi-channel Playback
<!–{v.name}–> |
Up to 16 channels |
| Record Mode
<!–{v.name}–> |
General, motion detection; intelligent; alarm; POS |
| Backup Method
<!–{v.name}–> |
USB device and network |
| Playback Mode
<!–{v.name}–> |
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Storage |
| Disk Group
<!–{v.name}–> |
Yes |
| Alarm |
| General Alarm
<!–{v.name}–> |
Motion detection; local alarm; alarm box; camera external alarm; network alarm; scene changing; PIR alarm; thermal alarm |
| Anomaly Alarm
<!–{v.name}–> |
Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exception |
| Intelligent Alarm
<!–{v.name}–> |
Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map |
| Alarm Linkage
<!–{v.name}–> |
Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; email |
| Port |
| Audio Input
<!–{v.name}–> |
1-channel RCA |
| Audio Output
<!–{v.name}–> |
1-channel RCA |
| Alarm Input
<!–{v.name}–> |
4 channels |
| Alarm Output
<!–{v.name}–> |
2 channels |
| Disk Interface
<!–{v.name}–> |
2 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature. |
| RS-232
<!–{v.name}–> |
1 |
| RS-485
<!–{v.name}–> |
1 |
| USB
<!–{v.name}–> |
2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
| HDMI
<!–{v.name}–> |
1 |
| VGA
<!–{v.name}–> |
1 |
| Network Port
<!–{v.name}–> |
1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| General |
| Power Supply
<!–{v.name}–> |
12 VDC, 4 A |
| Power Consumption
<!–{v.name}–> |
Total output of NVR is ≤ 10 W (without HDD) |
| Net Weight
<!–{v.name}–> |
1.57 kg (3.46 lb) |
| Gross Weight
<!–{v.name}–> |
2.73 kg (6.02 lb) |
| Product Dimensions
<!–{v.name}–> |
375.0 mm × 284.4 mm x 56.0mm (14.76″ × 11.20″ × 2.20″) (W × D × H) |
| Packaging Dimensions
<!–{v.name}–> |
433.0 mm × 141.0 mm × 366.0 mm (17.04″ × 5.55″ × 14.41″) (W × D × H) |
| Operating Temperature
<!–{v.name}–> |
–10 °C to +55 °C (14 °F to +131 °F) |
| Storage Temperature
<!–{v.name}–> |
–20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity
<!–{v.name}–> |
10%–93% (RH), non-condensing |
| Installation
<!–{v.name}–> |
Rack or desktop |
| Certifications
<!–{v.name}–> |
FCC: 47 CFR FCC Part15, SubpartB, Class A
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014 |
